1.lamp is made from high-quality aluminum allay with clear line, compact structure, nice exterior, good endurance, erosion proof and easy installation.
2.The surface of the lamp has been eelectrostatic sprayed and oxidize the positive anode with good temperature endurance and good endurance.
3.4mm-thin high-strength steel glass with high light transmittance and anti-shake ability
4.Ultra-brightness LED as light source and lighten the lamp
5.Multiple dynamic demonstration with red, yellow, white ,purple, orange, green and blue
6.The lamp could be installed separately or combined.
7.Unique waterproof design with special aluminum buckle with silicon rubber instead of relaying on glass glue to ensure the waterproof and dustproof function.
8.Grading option: 15°30°45°60°
技術分類
Technical Classification
項目規格
Item
參數
Parameter
電氣性能
Electrical Properties
供電電壓
Input voltage
AC85-265V
?最大功耗
Max Power Consumption
21W
光學性能
Optical Properties
?
?
光源組成
LED composition
15、18、21顆LED燈珠
15/18/21 LED lamp
光色
LED Color
綠色/紅色/藍色
Red/green/blue
光通量
Luminous flux
1785lm
光束角
Beam Angle
15°/30°/45°/60°
?
亮度燈具
Brightness Grade
每種顏色256級
256 grade percolor
光通維持率?????????
Luminous maintenance rate
30000 hour(@85%)
控制方式
Control Mode
控制接口
Interface
DMX512???????????
?
控制系統
Control System
中鳴科技
Easyplay5.0 (Joinmax)
結構性能
Structure
尺寸(長x寬x高)
Dimension (L*W*H)
1000X65X60(mm)
重量
Weight
3.5kg
燈體材料
Material
壓鑄鋁成型
Die-casting aluminum
表面顏色
Surface Color
銀灰色
Grey aluminum
燈具連接
Connection
4芯防水接插件
4-pin waterproof connector
防護等級
Protection Rating
IP65
工作溫度
Work Temperature
-20℃~50℃
工作濕度
Work Humidity
0~90%
使用環境
Work Environment
干燥/潮濕
Dry/wet
供電方式 Input Voltage | 發光顏色 LED Color | 產品編號 Model |
AC85-265V 單色色溫 (Monochrome Color Temp)2700-6500K ? | 單色1W/顆? 18顆?18W Single color 1W/pcs? 18pcs 18W | JM06-301801-017 |
單色1W/顆? 21顆?21W Single color 1W/pcs? 21pcs 21W | JM06-302102-017 | |
單色1W/顆?15顆?15W Single color 1W/pcs 15pcs 15W | JM06-301502-017 | |
RGB 1W/顆?21顆?21W RGB 1W/pcs 21pcs 21W | JZ06-302101-017 | |
RGB 1W/顆?15顆?15W RGB 1W/pcs 15pcs 15W | JZ06-301501-017 | |
DC24V | 單色0.06W/顆?144顆?12W Single color 0.06W/pcs 144pcs 12W | JZ06-114401-017 |
