- Functional Description
- Specifications
- Applications
1. Employ small-power, three in one LED as light source with high light efficacy, long working-life matching PC mask with high transmittance rate
2. Three color mix evenly and ?ideal effect could still be achieved when looked nearby.
3. Employ electricity supply from direct current power DC 24V, which could connect more lamps and save cable costs.
4. Aluminum alloy +PC enhance the heat-radiation effect greatly and compact small-size structure used for the installation and maintenance.
4. The protection ?grade has reached IP 65, suitable for indoor and outdoor use.
技術分類Technical?Classification | 項目規格Item | 參數Parameter |
電氣性能Electrical?Properties | 供電電壓Input?voltage | DC24V |
最大功耗Max.power?consumption | 10?W/m | |
光學性能Optical?Properties | 光源組成LED?composition | 36?pcs?of?SMD?LED |
像素間距?Pixel?Pitch | 27.5?mm | |
顯示像素Pixels | 36?像素/米?36?pixels/meter | |
光色LED?Color | 紅色/綠色/藍色?全彩色red/green/blue/amber/full?color | |
光束角Beam?Angle | 140° | |
亮度等級Brightness?Grade | 每種顏色256?級??256?grade?per?color | |
光通維持率Luminous?maintenance?rate | 50000?hour（@70%） | |
控制方式Control?Mode | 控制接口Interface | 2線串行接口?2-line?serial?interface |
控制系統Control?System | 中鳴科技Easyplay5.0 | |
結構性能Structure | 尺寸(長x寬x高)?Dimension?(L*W*H) | 1000X26X21（mm） |
重量?Weight | 0.5Kg | |
燈體材料Material | 擠壓鋁+磨砂PC???Die-casting?aluminium+?frosted?PC | |
表面顏色Surface?Color | 鋁原色?grey | |
燈具連接Connection | 4芯信號接插件，3芯電源接插件????4-pin?signal?connector?,?3-pin?power?connector? | |
防護等級IP?Grade | IP65 | |
工作溫度Work?Temperature | -20℃～50℃ | |
工作濕度Work?Humidity | 0～90% | |
最大級聯數Max.?cascade?connection?qty | 電源級聯8米，信號級聯?14米??8?meters?(power),?14?meters?(signal) | |
使用環境Work?Environment | 干燥/潮濕dry/humid | |
安全性能Safety | 認證Certificate | CE，CCC |
長度規格Length | 功率?Power | 發光顏色?LED?Color | 產品編號?Model | |
1000mm | 10?W | 紅色/綠色/藍色組合red/green/blue | JM07-203602RGB | 需申請 |
-
